Understanding how sparsely tuples are stored in a table

Today, we'll discuss tuples and their locations in pages – this is quite entry-level material but useful in many cases.

Understanding the physical layout of rows in tables may be important in many cases, especially during performance optimization efforts.

Some terms

• Page / buffer / block – unit of storage on disk and in Postgres buffer pool (loaded to RAM unchanged), in most cases 8 KiB (check it: show block_size;), it holds a portion of a table or index.
• Tuple – physical version of a row in a table.
• Tuple header – metadata about a tuple, including transaction ID, visibility info, and more.
• Transaction ID (same as XID, tid, txid) – unique identifier for a transaction in Postgres:
  • It's allocated for modifying transactions. Read-only ones have "virtualxid" to avoid "wasting" XIDs, since they are still 32-bit as of PG16. There is work in progress to switch to 64-bit.
  • You can get an XID allocated for your transactions by calling the function pg_current_xact_id() or, in PG12 and older, txid_current().

Tuple header has interesting "hidden", or "system" columns (docs):

• ctid – a hidden (system) column that represents the physical location of a tuple in a table, it has the form of two integers (X, Y), where:
  • X is the page number starting from 0
  • Y is the sequential number of a tuple inside the page starting from 1
• xmin, xmax – XIDs of transactions that created this row version (tuple), and deleted it (making this tuple "dead")

ctid

If we need to understand how sparsely some tuples are stored, we can just include ctid into the SELECT clause of the query. For example, we have the following table and a simple query to it:

nik=# \d t1
                      Table "public.t1"
 Column  |       Type       | Collation | Nullable | Default
---------+------------------+-----------+----------+---------
 id      | bigint           |           | not null |
 user_id | double precision |           |          |
Indexes:
    "t1_pkey" PRIMARY KEY, btree (id)
    "t1_user_id_idx" btree (user_id)

nik=# select * from t1 where user_id = 101469;
   id   | user_id
--------+---------
  28414 |  101469
 235702 |  101469
 478876 |  101469
 495042 |  101469
 555593 |  101469
 626491 |  101469
 635785 |  101469
 702725 |  101469
(8 rows)

To understand the physical locations of these rows, just include ctid in the SELECT clause of the same query:

nik=# select ctid, * from t1 where user_id = 101469;
    ctid    |   id   | user_id
------------+--------+---------
 (153,109)  |  28414 |  101469
 (1274,12)  | 235702 |  101469
 (2588,96)  | 478876 |  101469
 (2675,167) | 495042 |  101469
 (3003,38)  | 555593 |  101469
 (3386,81)  | 626491 |  101469
 (3436,125) | 635785 |  101469
 (3798,95)  | 702725 |  101469
(8 rows)

– each row is stored in a different page (153, 1274, etc). This is not the best situation for the performance of this query – a lot of IO is needed.

Now, if we want to see what tuples are present in page 1274, we can use a trick by converting ctid to point (via text since direct conversion is not possible) and extracting the first number of the two – the page number.

nik=# select ctid, * from t1 where (ctid::text::point)[0] = 1274 order by ctid limit 15;
   ctid    |   id   | user_id
-----------+--------+---------
 (1274,1)  | 235691 |  225680
 (1274,2)  | 235692 |  617397
 (1274,3)  | 235693 |  233968
 (1274,4)  | 235694 |  714957
 (1274,5)  | 235695 |  742857
 (1274,6)  | 235696 |  837441
 (1274,7)  | 235697 |  745413
 (1274,8)  | 235698 |  752474
 (1274,9)  | 235699 |  102335
 (1274,10) | 235700 |  908715
 (1274,11) | 235701 |  909036
 (1274,12) | 235702 |  101469
 (1274,13) | 235703 |  599451
 (1274,14) | 235704 |  359470
 (1274,15) | 235705 |  196437
(15 rows)

nik=# select count(*) from t1 where (ctid::text::point)[0] = 1274;
 count
-------
   185
(1 row)

– overall, there are 185 rows, and our row for user_id=101469 is also present, at position 12.

(Note, however, that this will be a very slow query for larger tables since it requires a Seq Scan, and we cannot create an index on ctid or other system columns. For queries that are aiming to find particular ctid (...where ctid = '(123, 456)'), though, performance is going to be good thanks to Tid Scan, see https://pgmustard.com/docs/explain/tid-scan).

ctid & BUFFERS metrics in execution plans

Confirming that the original query, indeed, involves many buffer operations (also see Day 1 where we talked about the importance of BUFFERS):

nik=# explain (analyze, buffers, costs off) select * from t1 where user_id = 101469;
                                                     QUERY PLAN
---------------------------------------------------------------------------------------------------------------------
 Index Scan using t1_user_id_idx on t1  (actual time=0.131..0.367 rows=8 loops=1)
   Index Cond: (user_id = '101469'::double precision)
   Buffers: shared hit=11
 Planning Time: 0.159 ms
 Execution Time: 0.383 ms
(5 rows)

– 11 buffer hits, it is 88 KiB. This is to retrieve 8 rows. Here is how we can determine the size of those 8 rows:

nik=# select sum(pg_column_size(t1.*)) from t1 where user_id = 101469;
 sum
-----
 317
(1 row)

Thus, the Postgres executor must handle 88 KiB to return 317 bytes – this is far from optimal. Since we have an Index Scan here, some of those buffer hits are index-related, some – to get data from the heap (table).

How to improve?

Option 0. Don't do anything but understand what's happening. Perhaps, you don't need to make significant improvements, as none of the options discussed below are perfect. Avoid over-optimization. But understand how sparse tuples are located and be ready to double-check it. In some cases, the fact that the target tuples are stored too sparsely can be a significant factor for query performance, leading to timeouts. In this case, do consider the following tactics.

Option 1. Maintain tables and indexes in good shape:

• Table bloat control: bloat is regularly analyzed, prevented by well-tuned autovacuum and regularly removed by pg_repack.
• Index maintenance: bloat control as well + regular reindexing, because index health declines over time even if autovacuum is well-tuned (btree health degradation rates improved in PG14, but those optimizations do not eliminate the need to reindex on a regular basis in heavily loaded systems).
• Partitioning: one of the benefits of partitioning is improved data locality.

Option 2. Use index-only scans instead of index scans. This can be achieved by using multi-column indexes or covering indexes, to include all the columns needed for our query. For our example:

nik=# create index on t1(user_id) include (id);
CREATE INDEX

nik=# explain (analyze, buffers, costs off) select * from t1 where user_id = 101469;
                                       QUERY PLAN
-----------------------------------------------------------------------------------------
 Index Only Scan using t1_user_id_id_idx on t1 (actual time=0.040..0.044 rows=8 loops=1)
   Index Cond: (user_id = '101469'::double precision)
   Heap Fetches: 0
   Buffers: shared hit=4
 Planning Time: 0.179 ms
 Execution Time: 0.072 ms
(6 rows)

– 4 buffer hits instead of 11, much better.

Option 3: Physically reorganize the table according to the index / column values: This is physical reorganization of the table. It has two downsides:

• You need to choose which index to use for it – only one index. Therefore, it will help only a specific subset of the queries in the workload and can be useless for other queries
• UPDATEs of the rows will move tuples, decreasing the benefits of CLUSTER, so it might be needed to repeat it.

There are two ways to reorganize the table

• SQL command CLUSTER (docs) – not an online operation, cannot be recommended for live systems that cannot afford maintenance windows
• pg_repack has option --order-by=<..>, which allows achieving an effect similar to CLUSTER but in an online fashion, without downtime.

For our example:

nik=# cluster t1 using t1_user_id_idx;
CLUSTER

And now the query:

nik=# explain (analyze, buffers, costs off) select * from t1 where user_id = 101469;
                                   QUERY PLAN
---------------------------------------------------------------------------------
 Index Scan using t1_user_id_idx on t1 (actual time=0.035..0.040 rows=8 loops=1)
   Index Cond: (user_id = '101469'::double precision)
   Buffers: shared hit=4
 Planning Time: 0.141 ms
 Execution Time: 0.070 ms
(5 rows)

– also just 4 buffer hits – same as for the approach with a covering index and an Index-Only Scan. Though, here we have an Index Scan.

---

That's it for today – we discussed ctid. Sometime in the future, we'll continue with xmin and xmax and a deep inspection of table/index pages for practical reasons.
